Product Description:
Model No: 0021068 (CBW-2)
Channel/Button: 2
Button Symbol: A, B
Operating Voltage: 9V (1 x 6F22 -9V battery, can be used for 12 months)
Operating Current: 30mA
Operating Frequency: 433Mhz
Encoding Chip: PT2262 / PT2264 / SC2262
Encoding Type: Fixed code by soldering, up to 6561 codes
Transmitting Distance: 1000m / 3000ft (theoretically)
The distance of 1000m is a theoretical data, it shall be operated in an open ground, no barriers, no any interference. But in the practice, it will be hindered by trees, walls or other constructions, and will be exposed to some interference by other signals. Therefore, the actual distance may or may not reach 1000m.
Waterproof case with external telescopic antenna.
If you stretches the external telescopic antenna, it can have a further working range, which is twice as much as it used to be.
Length of External Telescopic Antenna: 100mm / 460mm (stretch)
The transmitter has farther working range with external telescopic antenna.
With SMA connector
Modulation Mode: ASK
Operating Temperature: -20 ° C to +70 ° C
Unit Size: 100mm x 68mm x 50mm
Weight: 175g
Uses:
garage doors, motorcycles, car alarm products, home security products, wireless remote control products, industrial control products.
